Flexible, Scalable Design For Efficient 150kVA 150kW Solar Power Plant. With Lithium-ion Battery Off Grid Solar System For A Factory, Hotel, or House Communities.
Place Of Origin: China
MOQ: 1 set, accept OEM & ODM
Type: 150kw off-grid solar system
Commercial off-grid microgrid solution
Wind/battery/grid or generator optional backup
The following configurations make up a complete 150kva 150kW solar power plant:
Item | Model | Description | Quantity |
1 | Solar Panel | Mono 580W TOPCon | 260 pieces or Customized |
2 | PV combiner | H6T 360V | 5 sets |
3 | Solar controller | 360V 100A – MPPT charge controller | 5 sets |
4 | Pure Sine Wave Inverter | 150kW IGBT inverter | 1 set |
5 | Battery | 2V1200Ah gel battery or Lithium Battery optional | 180 pieces |
6 | Mounting Support | Ground or Slope roof or Flat roof optional | 260 pieces or Customized |
7 | Cables and others | 1)Copper row 1set for connection 180 batteries | 900 meters or Customized |
Optional solar mounting support, PV combiner boxes, and cables.
PVMARS provides a complete turnkey PV energy storage system solution. After we complete production, the system delivered to you can be used immediately after connections are made. You don’t need additional accessories to benefit from it.
The premise of providing a complete 150kw solar power plant solution requires: You only need to submit load (electrical equipment) information, pictures/drawings of the installation location, output voltage range, and other data.
PVMARS’s engineering team can provide a complete solar system (off-grid or mini-grid solution).
It is recommended that you download this load table, compare it, and fill in the corresponding information: (This form is not mandatory. If there is no electrical equipment in use, please inform PVMARS of your budget and we will configure it according to your).
150kW solar power plant prices US$107,077 – Gel battery design. (Valid for 30 days).
Note: If you need a quote for lithium battery design, please contact [email protected] to obtain it.
Below are the product parameters and pictures of the 150kw solar plant.
Strong anti-cracking, heat spot protection
PVMARS provides monocrystalline and polycrystalline solar panels from 50w-600w.
Among them, monocrystalline N-type TOPCon solar panels are currently a popular option because their high conversion efficiency and low degradation rate make them more efficient than P-type solar panels.
Based on the average lighting time of about 4-6 hours, a 150kw solar panel can generate 603kWh-905kWh per day, about 27,144kWh per month, and about 325,728kWh per year.
Solar panels generate power related to the amount of sunshine in your local area. Click on this article to learn more.
Data sheet under STC Condition | |
Maximum power at STC(Pmax) | 580 Watts |
Optimum operating voltage (Vmp) | 43.22V |
Optimum operating current(Imp) | 13.42A |
Open-circuit voltage(Voc) | 51.41V |
Short-circuit current(Isc) | 14.22A |
Module efficiency(%) | |
STC: Irradiance 1000W/㎡,Module temperature 25°℃,AM=1.5 NMOT:Irradiance 800W/㎡,wind speed:1m/s,Module temperature 20℃ Tolerance of Pm:0~+5W This is laboratory data and may deviate from actual use. | |
Mechanical Parameters | |
Cell | N Type Mono-crystalline silicon solar cells |
Cell Size | 182mm*91mm |
Cell Quantity | 144Pcs(6*24) |
Dimension of module | 2279mmx1134mmx30mm |
Weight | 27.5kg |
Junction Box | Separated Junction Box with 3 diodes |
Output Cables | 4mm2 |
Operating temperature | -40℃ to 85℃ |
Specifications are subject to change without further notification | |
H6T-360VDC
Multiple solar panel string inputs
PV array wiring simplified, controller protection,
Wide range of DC input voltages, max circuit voltage: 1000V
Reliable thunderstorm & surge protection
Real MPPT solar controller
DC voltage:360V
Rated current: 100A
MPPT efficiency >99.9%, Max input voltage:800V various protection functions
PVMARS conventional inverters can choose between MOS tubes and IGBT modules, but we recommend IGBT modules.
The IGBT is more efficient than the MOS tube, but the price will also increase accordingly (if you’re interested in the MOS tube inverter, please contact us).
An IGBT (Insulated Gate Bipolar Transistor) is a super-electronic switch that withstands extremely high voltages.
The AC voltage of a typical house is 220V, and the paper-thin IGBT chip can withstand 6500V. And it can flow 200A of current!
It is very suitable for precision instruments, factories, hospitals, and large shopping malls.
This powerful IGBT inverter deserves your house. You deserve better!
Model | MT-150kW |
Capacity(W) | 150,000W |
DC voltage(V) | 360-380 |
Input voltage(V) | 380V± 20%(3 phase), phase voltage 220V |
Input frequency | 45~65Hz |
Output voltage | 380/400/415V optional+ -1% for static load, 5% for fluctuant load |
Output wave form | Pure sine wave |
Total-harmonic- distortion | < 3% linear load, < 5%( nonlinear load) |
Transfer time | Inverter / bypass transfer switch time(Overload): 0ms inverter / bypass transfer switch time (fault inverter) 1ms |
Transfer Efficiency Protections | 90%–95% |
Protections | Protection against short-circuit, over load, high-voltage, reverse polarity protection and low-voltage protection |
Overload | Overload 125% for 10 mins, 125%-150% for 1 min. automatically resume when the load becomes normal |
The gel battery of this 150kw solar plant is designed with 180pcs 2v1200ah batteries with a total capacity of 432kWh.
Model: MG2V- 1200 | ||
Design Life | 12 years | |
Nominal Capacity | 20HR(64.8A,1.80V) | 1296Ah |
10HR(120A,1.80V | 1200Ah | |
3HR(324A,1.80V) | 972Ah | |
1HR(660A,1.80V) | 660Ah | |
Internal Resistance | 0.26mΩ(Full Charge) | |
Self Discharge | s3% per month | |
Charge Voltage | Cycle Use | Standby Use |
2.33V/Cell (-4mV/’C/Cell) Max. Charge Current:180A | 2.23V/Cell (-3mV/”C/Cell) | |
In addition, PVMARS also offers lithium battery options. If your installation location is limited and you want more power, our small-volume 432kWh lithium battery is also an excellent choice.
Please contact our sales team for specific prices.
Full set for Slope, Flat roof or Ground land optional
Including complete fittings
Wind load: 55m/s, snow load:1.5kn/m2
Structure: Anodized aluminum + stainless steel
Customized as per user’s requirement
Junction boxes, cabling, lighting, sensors, breakers
1) Copper row for connection to battery
2) 4mm2 PV cable, 25mm2 cable, 32mm2 cable etc.
3) full set of install tools, terminals and MC4 and 2P/4P switch box
100% EL TESTING, 100% IV TESTING, 100% DIGITAL WORKSHOP
In strict accordance with the German 5S technical standard, our production workshop has marked the production time, model, quantity, and other information for each raw material. Successfully ensure the high quality and efficiency of finished products.
PVMARS solar products have passed TUV, IEC, ISO, CE, and RoHS quality certifications.
Before leaving the factory, our testers will perform no less than 120 extreme impact tests, and all kinds of inspections in order to get your approval.
With PVMARS solar IoT, through your phone or computer view real-time performance data of your solar system, such as solar panel power generation, battery capacity, etc., and receive timely maintenance and safety alerts to extend the life of your solar system.
At the same time, your dedicated engineers will help you adjust the data through IOT. Double protection!
Mr. Li, the founder of PVMARS Solar, has been to more than 32 countries for field surveys and solar energy storage system installation. He has trained 5 core solar system and wind turbine system installation experts, as well as a number of overseas installers.
If you need our overseas installation service, the engineer will arrive at the installation site within 10 days after the goods arrive at the port.
In addition, for users who purchase our photovoltaic energy products, wind turbine products, solar all in one street led light products, and solar air conditioning products, we will provide the paper version of installation instructions and electrical drawings with the shipment of goods, as well as the electronic version online.
For the needs of different users, to ensure the correct installation of the product, your dedicated engineers have been waiting online, at any time to video remote communication with you, patiently guide you step by step to complete the installation, and debug the operation of the machine etc. Ensure that you are protected from all hidden dangers.
By partnering with experienced PVMARS Solar, you can be confident that your installation project will be successful. This will meet your renewable energy needs for 25 years and more.
