Check Lithium Battery Factory price, over 15 years life span, and help you create power in Remote areas/Home/Farm/Hotel/Commercial. Solve power shortage. Battery Energy Storage System
MOQ: 1 set, accept OEM & ODM
Type: Off-grid with battery back up
Payment: T/T, L/C, Paypal, Western Union
Leading photovoltaic energy storage technology
Intelligent remote monitoring of 24-hour power supply
We only care about how YOU feel
To your satisfaction
100% EL TESTING, 100% IV TESTING, 100% DIGITAL WORKSHOP
In strict accordance with the German 5S technical standard, our production workshop has marked the production time, model, quantity, and other information for each raw material. Successfully ensure the high quality and efficiency of finished products.
PVMARS products have passed TUV, IEC, ISO, CE, and RoHS quality certifications.
Before leaving the factory, our testers will perform no less than 120 extreme impact tests, and all kinds of inspections in order to get your approval.
Your dedicated engineers are ready to start customizing your energy storage system!
Product Model | DD7680 | DD10240 | DD15360 | DD20480 | |
| Battery pack | |||||
| Battery pack modle | 51.2V50Ah | 51.2V50Ah | 51.2V100Ah | 51.2V100Ah | |
| Battery cell type | LiFePO4 | ||||
| Serial/Parallel | 16S3P | 16S3P | 16S4P | 16S4P | |
| Battery pack dimension | 530*420*161MM | 530*420*161MM | 700*460*166MM | 700*460*166MM | |
| Battery pack weight | 26KG | 26KG | 38KG | 38KG | |
| Number of battery packs | 3pcs | 3pcs | 4pcs | 4pcs | |
| System parameters | |||||
| Rated voltage | 51.2V | ||||
| Working voltage range | 40V-58.4V | ||||
| Charge voltage | 54.4V-55.2V | ||||
| Floating charge voltage | 53.6V-54.4V | ||||
| Rated capacity | 150Ah | 200Ah | 300Ah | 400Ah | |
| Energy | 7.68KWH | 10.24KWH | 15.36KWH | 20.48KWH | |
| Rated charge current | 100A | ||||
| Peak charge current | 100A | ||||
| Rated discharge current | 100A | ||||
| Peak discharge current | 150A | ||||
| Product dimension（L*W*H） | 450*145.5*620MM | 450*145.5*620MM | 450*235*650MM | 450*235*650MM | |
| Other parameters | |||||
| Charge temperature | 47KG | 49KG | 89KG | 92KG | |
| Discharge temperature | 0-55℃ | ||||
| Optimum temperature | -10-55℃ | ||||
| Cooling method | Natural cooling | ||||
| Relative humidity | 5%-95% | ||||
| Altitude | ≤2000M | ||||
| Cycle life | ≥6000 @80%DOD，0.5C/0.5C，25℃ | ||||
| Communication interfaces | CAN2.0/RS485/RS232 | ||||
| Protection | Over temperature, over current, over voltage, insulation and other multiple protection ,etc. | ||||
| Display | LCD touch screen | ||||
| Design lifetime | ≥15 years | ||||
| Certification | UN38.3/UL1973/IEC62619(cell) | ||||
We use high-performance and high-capacity batteries that last for a long time, so you can use them from morning to night, and the performance is stable!
5kW lithium battery Up to 30kWh per day
10kW lithium battery Up to 70kWh per day
15kW lithium battery Up to 100kWh per day
Mr. Li, the founder of PVMARS Solar, has been to more than 32 countries for field surveys and solar energy storage system installation. He has trained 5 core solar system and wind turbine system installation experts, as well as a number of overseas installers.
If you need our overseas installation service, the engineer will arrive at the installation site within 10 days after the goods arrive at the port.
In addition, for users who purchase our photovoltaic energy products, wind turbine products, solar all in one street led light products, and solar air conditioning products, we will provide the paper version of installation instructions and electrical drawings with the shipment of goods, as well as the electronic version online.
For the needs of different users, to ensure the correct installation of the product, your dedicated engineers have been waiting online, at any time to video remote communication with you, patiently guide you step by step to complete the installation, and debug the operation of the machine etc. Ensure that you are protected from all hidden dangers.
By partnering with experienced PVMARS Solar, you can be confident that your installation project will be successful. This will meet your renewable energy needs for 25 years and more.
500KW - 2MW
In this world, there are many clean energy sources, but only photovoltaicss is the most reliable power supply. The closest to our life is a kind of renewable energy everywhere. The future of photovoltaic energy will be because of technological innovation, and the cost will be lower, we will live an independent and free life.
PVMARS Solar is one of the most innovative manufacturers of solar energy storage technology.
This is for you to pursue safer, more convenient, and more competitive prices for solar products.
Direct manufacturer pricing, no middleman markups.
We are able to offer durable equipment at competitive price.
Q: What does this PVMARS system include?
A: A complete off-grid or on-grid solar clean energy system, including all accessories required for installation.
Q: Can I customize one?
A: Of course, you can customize the most efficient solar power system. Your exclusive solar expert is waiting. To provide you with any energy solution, customized according to different power consumption, actual use of equipment, scenarios etc. Solar systems come in different configurations.
Q: Who is responsible for transportation? Or home delivery?
A: There will be dedicated staff responsible for your products’ production, packaging and shipping. To deliver goods safely to the destination port by sea or air. The entire process, including transportation and customs clearance, is handled by us. Europe, Asia, Africa to provide home delivery or nearby pickup service. Provide relevant packing and shipping documents and information on time.
Q: What is the lifetime of a solar power system?
A: The life of the solar panel is 25 years, the charger controller is 5-7 years, the inverter is 5-7 years, and the battery is 8-10 years. Our IOT monitors the installation and operation of your solar power system in real time to extend service life.
Q: Are there any protection measures for solar power overload, and how do electricity leaks, lightning strikes, and hail happen?
A: PVMARS Solar’s PV combiner box and inverter have overload safety functions. To protect each other, they will disconnect the connection with your equipment in the event of abnormal voltage, such as lightning strikes and leaks. After the voltage is restored automatically, the solar system will start automatically. Secondly, the photovoltaic module floor is made of excellent impact-resistant tempered glass. This glass can withstand 200Pa wind stress and 7200Pa snow stress after strict trial and test when passing EU certification.
Q: What can you expect from PVMARS Solar?
A: In addition to providing products, PVMARS solar also provides free on-site survey, customized design solutions, production, installation and maintenance one-stop services.
Our broadcast station is located at the top of the mountain, and we have used diesel generators before. We worry about the diesel transportation of the generators, maintenance, and voltage instability every day.
The current power source is the 30kw hybrid solar wind energy system. In our limited budget and installation area, PVMARS recommends using a solar wind system. This can reduce the battery footprint, but also provide a 24-hour uninterrupted and stable power supply.
It’s awesome how much I save on my partner’s bill with 10kw solar and battery package, but for me, it’s the peace of mind that I can use our electrical appliances knowing that we have clean energy. I’ve already recommended them to family members because they’ve been friendly, upfront, and responsive.
500kw solar energy storage system has operated in our remote countryside for two years. This week, Dunsborough experienced another blackout. Now we are happy to tell you that our town is not affected. All houses keep the lights on, use refrigerators, surf the Internet and listen to music to relax. This is thanks to PVMARS solar company, which customized the solar battery system according to our town’s electricity demand. This has greatly improved our local residents’ happiness index.
There was no problem with the installation, the instructions and online remote video install guidance were great, the system is working great and I’m producing 90% of my power. I just got my first bill back, last year $1290, this year $119, it’ll pay for itself in two years at this rate. You just have to adjust your times for power usage and you’ll save a lot.
The 5kw solar storage system was installed in 2018. We were initially attracted to the idea of using lithium batteries at night while solar power supply our house during the day. In addition, it can also provide seamless grid failure protection. At that time we did not know that the main city power had been cut off, until we saw outside, originally brightly lit streets and houses, because there is no electricity change to dark, to realize that the city grid has been cut off. And our house because of solar energy, to achieve power independence, electricity freedom.
We have seen an immediate reduction in our energy bills and a change in our power consumption patterns since we installed the PVMARS off-grid solar power system. And PVMARS IOT is so smart to remind me why my battery is running so fast. We can also contribute power back to the grid over the summer, which is a big plus.
