PVMARS’ high-quality all-in-one 100kw solar wind generator continues to generate electricity 24/7, 100kw wind solar hybrid system saves you 100% on electricity bills.
Commercial and industry solar wind turbine solution
Place Of Origin: China
MOQ: 1 set, accept OEM & ODM
Type: 100kW solar wind generator hybrid system
Price Term: EXW
Can work with battery/city grid or diesel generator backup
100kW solar wind generators are the most affordable, reliable, and mature renewable energy technology for 24-hour power generation.
When we wake up in the morning, may see the morning sun. As the sun radiates heat relentlessly, the 100kW solar wind turbine absorbs and converts it into electricity.
When the sun and you finish their work for the day, you enjoy the breeze on your way home. In the meantime, your wind generator also rotates with the wind.
Your factory, farm, resort, school, and other buildings are powered by mechanical and kinetic energy.
In addition to generating electricity, they also let you use electricity freely and enjoy a top-notch life.
You get solar panels and wind turbines, but what else does PVMARS’s 100kw solar wind generator offer?
Item | Model | Description | Quantity |
1 | Solar Panel | Mono 580W TOPCon | 91 pieces or Customized |
2 | PV combiner | H4T 360V | 2 sets |
3 | Solar controller | 360V 100A – MPPT charge controller | 2 sets |
4 | Wind turbine | Horizontal axis 50kW wind turbine | 1 set or Customized |
5 | Wind controller | 50000W wind charge controller | 1 set |
6 | Pure Sine Wave Inverter | 100kW IGBT inverter | 1 set |
7 | Battery | 2V1000Ah gel battery or Lithium Battery optional | 180 pieces |
8 | Mounting Support | Ground or Slope roof or Flat roof optional | 91 sets or Customized |
9 | Guy cable pole | 18 meters for fixed 50kW wind turbine | 1 set or Customized |
10 | Cables and others | PV cables, wind cables and install tools | 1000 meters or Customized |
Note: Installation and connection of 100kw solar wind generators require mounting support, a guy cable pole, wires, and other accessories.
PVMARS originally intended to provide the full set 100kw solar wind turbine system. Then you don’t need to buy other accessories locally.
But they are auxiliary functions. If you don’t need them, contact [email protected] for a customized quotation. A customized solution for the 100kw solar wind generator will be provided within 1 hour at the fastest.
Based on the design of a 2v1000ah gel battery, a complete 100kw solar wind turbine is priced at US$98,089. (Valid for 30 days)
If you need a quote for lithium battery design, please contact [email protected] to obtain it.
The pictures below are just examples. If you want to know more details about the installation, please browse below:
This 100kW solar wind generator is for households with a daily electricity consumption of over 600KWH.
We know that the power generation of this system is provided by solar panels and wind turbines, so PVMARS will describe them separately.
PVMARS provides monocrystalline and polycrystalline solar panels from 50w-600w.
Among them, monocrystalline N-type TOPCon solar panels are currently a popular option because their high conversion efficiency and low degradation rate make them more efficient than P-type solar panels.
We provide videos and parameters here for your reference.
A 100kW solar wind generator system is generally equipped with 91pcs 580W solar panels.
The number of solar panels is closely related to electricity consumption. We can read the article “How many solar panels do I need?” together to get more inspiration.
Data sheet under STC Condition | |
Maximum power at STC(Pmax) | 580 Watts |
Optimum operating voltage (Vmp) | 43.22V |
Optimum operating current(Imp) | 13.42A |
Open-circuit voltage(Voc) | 51.41V |
Short-circuit current(Isc) | 14.22A |
Module efficiency(%) | |
STC: Irradiance 1000W/㎡,Module temperature 25°℃,AM=1.5 NMOT:Irradiance 800W/㎡,wind speed:1m/s,Module temperature 20℃ Tolerance of Pm:0~+5W This is laboratory data and may deviate from actual use. | |
Mechanical Parameters | |
Cell | N Type Mono-crystalline silicon solar cells |
Cell Size | 182mm*91mm |
Cell Quantity | 144Pcs(6*24) |
Dimension of module | 2279mmx1134mmx30mm |
Weight | 27.5kg |
Junction Box | Separated Junction Box with 3 diodes |
Output Cables | 4mm2 |
Operating temperature | -40℃ to 85℃ |
Specifications are subject to change without further notification | |
PVMARS’s 100kw hybrid system has a 50kW horizontal axis. If your local average wind speed is higher than 5m/s and the installation space is limited, we can reduce the number of solar panels and increase the wind turbine’s power.
PVMARS’ hybrid wind-solar hybrid system is very flexible. As long as you tell us what challenges you are facing, our experienced engineers will provide you with a satisfactory design solution.
The following are the parameters of a 50kW horizontal axis wind generator:
Model | MF-50000 |
Rated power | 50000W |
Starting wind speed | 2.5m/s |
Rated voltage | 220V/240V/380V |
Rated wind speed | 11m/s |
Security wind speed | ≤50m/s |
Rated DC voltage | 360V |
Number of blades | 3 |
Wind blade diameter | 13.2m |
Rated speed | 110rpm |
Control mode | Electric brakes |
Generator type | 3 phase AC permanent magnet synchronous generator / Lightning protection module + lightning protection grounding |
Fuselage material | Reinforced die-cast aluminum+steel |
Temperature | -40℃ ~ 80℃ |
Service life/Degree of protection | ≥ 20 years / IP54 |
Packing material | Foam and plywood |
N.W&G.W(kg) | ≈2000kg |
Packing size | 147*72*96cm + 461*55*50cm + 65*65*32cm + 145*120*6cm 50kw wind turbine is packaged in these 4 parts – wind blades, generator and other accessories |
Click on the orange font to find out the price and details of a standalone 50kw wind system.
Note: If the average wind speed is less than 5m/s, PVMARS has vertical axis and horizontal axis wind turbines.
Vertical-axis wind turbines cost more than horizontal axis. However, it is not limited by wind speed, and it can generate electricity even at a wind speed of 1m/s.
Click “Compare various types of wind turbines” to learn more.
An inverter is the core of the system.
Wind and sun power flow into the battery through the wind and solar hybrid controller, and the battery converts direct current.
If your appliances use AC power (such as refrigerators, air conditioners, and washing machines), you need an inverter to convert DC power into AC power.
Among them, the inverter power is closely related to the electrical load power you use. if your house power exceeds 100kw. Our team can design a 150kw inverter and a 100kw solar wind turbine, or bigger.
PVMARS conventional inverters can choose between MOS tubes and IGBT modules, but we recommend IGBT modules.
The IGBT is more efficient than the MOS tube, but the price will also increase accordingly (if you’re interested in the MOS tube inverter, please contact us).
An IGBT (Insulated Gate Bipolar Transistor) is a super-electronic switch that withstands extremely high voltages.
The AC voltage of a typical house is 220V, and the paper-thin IGBT chip can withstand 6500V. And it can flow 200A of current!
It is very suitable for precision instruments, factories, hospitals, and large shopping malls.
This powerful IGBT inverter deserves your house. You deserve better!
The 100kw IGBT inverter has the following parameters:
Model | MT-100kW |
Capacity(W) | 100,000W |
DC voltage(V) | 360-380 |
Input voltage(V) | 380V± 20%(3 phase), phase voltage 220V |
Input frequency | 45~65Hz |
Output voltage | 380/400/415V optional+ -1% for static load, 5% forfluctuant load |
Output wave form | Pure sine wave |
Total-harmonic- distortion | < 3% linear load, < 5%( nonlinear load) |
Transfer time | Inverter / bypass transfer switch time(Overload): 0ms inverter / bypass transfer switch time (fault inverter) 1ms |
Transfer Efficiency Protections | 90%–95% |
Protections | Protection against short-circuit, over load, high-voltage, reverse polarity protection and low-voltage protection |
Overload | Overload 125% for 10 mins, 125%-150% for 1 min. automatically resume when the load becomes normal |
Note: The output voltage designed for the 100kW IGBT inverter on this page is three-phase 380v-415v
If you request dual voltage 120v/240v, please leave a message about the required output voltage and email [email protected] to get a quote for customized output.
The gel battery of this 100kw wind and solar hybrid system is designed with 180pcs 2v1000ah batteries with a total capacity of 360kWh.
But to extend battery life, gel batteries have deep cycles of 85%-90%. That means the total capacity should be 324kWh.
The battery capacity is related to the time you use electrical appliances.
If you only turn on air conditioners, computers, TVs, refrigerators, and other loads at night, the 324kwh battery capacity is also sufficient. This is because wind turbines provide continuous power at night.
In addition, PVMARS also offers lithium battery options. If your installation location is limited and you want more power, our small-volume 1-unit 360kWh lithium battery is also an excellent choice.
Please contact our sales team for specific prices.
Generally speaking, the installation area of a 100kW solar-wind hybrid system is approximately 260 square meters (2799 ft2).
Solar panels are calculated from the roof area: 91 x 580W PV panels occupy approximately 237 square meters. 180 x 2v 1000AH gel batteries will require approximately 5.6 square meters of installation area.
There are also relatively small proportions of inverters. Solar and wind controllers can be mounted on the wall.
Therefore, we should consider the installation area inside and outside the house.
PVMARS has detailed articles and installation manuals to choose from. Please click on the orange font to get them.
If you want someone to help you install, PVMARS has an overseas installation team. We have been to Turkey to install 5 sets of 30kw wind turbines.
It is worth noting that the team’s installation costs, round-trip air tickets, accommodation, food, and security will all be the buyer’s responsibility.
Therefore, PVMARS recommends setting up according to the installation manual we provide.
If it cannot be completed, you can contact us for online video assistance or arrange for an engineer to come to your address.
MPPT intelligent control
50000W wind power
360V intelligent control Lightning protection.
Wind turbine current limiting, Wind turbine automatic brake, and manual brake.
Real MPPT solar controller
MPPT efficiency >99.9%, Max input voltage:800V various protection functions
For 50kw wind turbine, we suggest 18m or 20m height tower optional
It helps fasten the wind generator to a safe altitude.
Use steel material with rust prevention.
Easy to install
H4T-360VDC
Multiple solar panel string inputs
PV array wiring simplified, controller protection,
Wide range of DC input voltages, max circuit voltage: 1000V
Reliable thunderstorm & surge protection
Full set for Slope, Flat or Ground roof optional
Including complete fittings
Wind load: 55m/s, snow load:1.5kn/m2
Structure: Anodized aluminum + stainless steel
Can be customized as per user’s requirement
1) Battery cables and Copper row for connection to battery
2) 4mm2 PV cable and 25mm2 wind cable
3) full set of install tools, terminals and MC4 and 2P300A switch box
Before each loading and shipment, our factory has special personnel to check the QC inspection of qualified products.
They distinguish and mark the area to place, ensure the shipment quantity, model, customer name is accurate, only after the standard is allowed to load containers.
Ensure that you receive complete and correct goods at the end.
Carton and Wooden box packing optional-Solar panel
100% EL TESTING, 100% IV TESTING, 100% DIGITAL WORKSHOP
In strict accordance with the German 5S technical standard, our production workshop has marked the production time, model, quantity, and other information for each raw material. Successfully ensure the high quality and efficiency of finished products.
PVMARS products have passed TUV, IEC, ISO, CE, and RoHS quality certifications.
Before leaving the factory, our testers will perform no less than 120 extreme impact tests, and all kinds of inspections in order to get your approval.
With PVMARS IoT, through your phone or computer view real-time performance data of your energy system, such as solar panel and wind power generation, battery capacity, etc., and receive timely maintenance and safety alerts to extend the life of your hybrid system.
At the same time, your dedicated engineers will help you adjust the data through IOT. Double protection!
50KW
500KW - 2MW
Direct manufacturer pricing, no middleman markups.
We are able to offer durable equipment at competitive price.
We have seen an immediate reduction in our energy bills and a change in our power consumption patterns since we installed the PVMARS off-grid solar power system. And PVMARS IOT is so smart to remind me why my battery is running so fast. We can also contribute power back to the grid over the summer, which is a big plus.
Our broadcast station is located at the top of the mountain, and we have used diesel generators before. We worry about the diesel transportation of the generators, maintenance, and voltage instability every day.
The current power source is the 30kw hybrid solar wind energy system. In our limited budget and installation area, PVMARS recommends using a solar wind system. This can reduce the battery footprint, but also provide a 24-hour uninterrupted and stable power supply.
It’s awesome how much I save on my partner’s bill with 10kw solar and battery package, but for me, it’s the peace of mind that I can use our electrical appliances knowing that we have clean energy. I’ve already recommended them to family members because they’ve been friendly, upfront, and responsive.
500kw solar energy storage system has operated in our remote countryside for two years. This week, Dunsborough experienced another blackout. Now we are happy to tell you that our town is not affected. All houses keep the lights on, use refrigerators, surf the Internet and listen to music to relax. This is thanks to PVMARS solar company, which customized the solar battery system according to our town’s electricity demand. This has greatly improved our local residents’ happiness index.
There was no problem with the installation, the instructions and online remote video install guidance were great, the system is working great and I’m producing 90% of my power. I just got my first bill back, last year $1290, this year $119, it’ll pay for itself in two years at this rate. You just have to adjust your times for power usage and you’ll save a lot.
The 5kw solar storage system was installed in 2018. We were initially attracted to the idea of using lithium batteries at night while solar power supply our house during the day. In addition, it can also provide seamless grid failure protection. At that time we did not know that the main city power had been cut off, until we saw outside, originally brightly lit streets and houses, because there is no electricity change to dark, to realize that the city grid has been cut off. And our house because of solar energy, to achieve power independence, electricity freedom.
