0 Electricity bill | 0 Noise with Energy Storage System

DIY 3kW Wind Solar Energy Generator Hybrid System for House

Get a 3kW Wind Solar Energy Generator Hybrid System best price, help you create power in remote areas/office/home/factory. Solve power shortages.

Brand: PVMARS Solar Manufacturer

MOQ: 1 set, accept OEM & ODM

Type: Hybrid solar wind energy

Output voltage: 220V-110V Single/Double phase

Payment: T/T, L/C, Paypal, Western Union

PVMARS establishment time and advantages

16 years

Leading solar and wind energy storage technology

24 hours uninterrupted power supply solution

24 hours

Intelligent remote monitoring of 24-hour power supply

Meticulous and warm solar expert

24/7 online

We only care about how YOU feel
To your satisfaction

Manufacturer of solar power clean energy

PVMARS Solar Factory -100% Lab

100% EL TESTING, 100% IV TESTING, 100% DIGITAL WORKSHOP

In strict accordance with the German 5S technical standard, our production workshop has marked the production time, model, quantity, and other information for each raw material. Successfully ensure the high quality and efficiency of finished products.



Global authoritative certification

PVMARS products have passed TUV, IEC, ISO, CE, and RoHS quality certifications.

Before leaving the factory, our testers will perform no less than 120 extreme impact tests, and all kinds of inspections in order to get your approval.



PVMARS Solar Energy Storage Factory Certificate Of Authority

Safety reminder for solar wind system

With PVMARS IoT, through your phone or computer view real-time performance data of your energy system, such as solar panel and wind power generation, battery capacity, etc., and receive timely maintenance and safety alerts to extend the life of your hybrid system.

At the same time, your dedicated engineers will help you adjust the data through IOT. Double protection!




How do 220v and 380v AC output voltages differ?

PVMars single phase 220v-240vac

Single phase: 110V/120V/220V/230V/240V ±5%

PVMars three phase 380v-415vac

Three phase: 380Vac/400Vac±10%(customized 190Vac/200VAC)

For most 220VAC appliances, the voltage is single-phase. Such as air conditioners, fan, light, TV, and so on.

BTW, PVMars clean energy system also can produce double/dual voltage output, which means L1+N =110V – L2+N=110V – L1+L2=220VSplit phase capable/dual output voltage

For most 380VAC-415VAC appliances, the voltage is three-phase. Such as motors, power pumps, central air conditioning, industrial equipment, and so on.

Your dedicated engineers are ready to start customizing your hybrid solar wind clean energy system!

3000 watt hybrid solar wind power system Load reference

3000 watts wind energy solar panel power Home System Load Reference
Load NameLoad Rated PowerQTYTotal Rated Power
Lights11W444W
Fan80W180W
Computer150W1150W
Washing machine150W1150W
Refrigerator100W1600W
Electric cooker200W1200W
Air conditioner(0.5HP)360W11080W
Color TV200W1200W
Water Pump100W1400W
Total2904W

This example is just for reference. But your load can be less than 3kw

Remark: Refrigerator, air conditioner and water pump are inductive loads, start working power is 3-6 times more than normal power, in the process of use, turn on the inductive load first

3kW Hybrid Solar Wind Energy Generator System Description

Maximum 600 Watts solar panel optional

Shingled/HJT solar panel, USA TR Technology panel, higher efficiency, longer life
Vmp:39V – Voc:47.13V – Imp 12.3A – Isc:12.91A
25 years guarantee (CE TUV).
Strong anti-cracking, heat spot protection

               Solar panel

Battery

Capacity: 12V100Ah-250Ah gel battery

Or 48-96V100Ah-400Ah Lithium (LFP cell) battery –Stackable

The latest in through-wall welding and full-sealing technology.
More suitable for motor loads.
Service life: 8-10-15 years

Battery-stackable-energy-storage-system

3 kilowatt IGBT inverter

Single/Dual Phase Inverter optional

3kW/48VDC-96VDC optional

Single phase AC output: 110V/120V/220V/230V/240VAC 50/60HZ
Dual phase AC output: 220V and 110V 50/60HZ

Waveform: Pure Sine Wave
100% Fuji brand IGBT materials

Bypass function with AC charger, against short-circuit and over-load protection, high-voltage and low-voltage stable protection

Wall-mounted type optional

20kW IGBT inverter

Wall-mounted hybrid inverter



Inverter appearance color can be selected

MPPT solar wind hybrid controller

MPPT intelligent control

3000W solar wind power
48V-96V intelligent control Lightning protection.

Wind turbine current limiting, Wind turbine automatic brake and manual brake.

Wind controller with dump load

1kW/2kW Wind turbine/Windmill optional

Wind Power: 1kW-2kW/48V-96V optional
Starting wind speed: 2-3m/s                            Rated wind speed: 10-13m/s
Security wind speed: 40-60m/s                        Rated speed: 185-300r/m

Wind Blade material: Extra-strong fiberglass        3 years warranty, 20 years use life

   Vertical wind turbineHorizontal axis wind turbine

Vertical-axis and horizontal-axis wind turbines are optional

Guy cable pole/Stand alone tower optional

6m-12m height optional
It helps fasten wind generator in safe altitude.
Use steel material with rust prevention.
Easy to install

Guy cable poleStand alone tower for windmill

PV combiner optional

H4T-H10T 48VDC-96VDC optional
Multiple solar panel string inputs
PV array wiring simplified, controller protection,
Wide range of DC input voltages, max circuit voltage: 1000V

Reliable thunderstorm & surge protection

PV combiner

Solar Panel Rack/Bracket Optional

Full set for Slope, Flat or Ground roof optional

Including complete fittings

Wind load: 55m/s, snow load:1.5kn/m2

Structure: Anodized aluminum + stainless steel

Can be customized as per user’s requirement

            Solar panel rack

Cables and Accessory

1) Battery cables and Copper row for connection to battery

2) 4mm2 PV cable and 25mm2 cable

3) full set of install tools, terminals and MC4 and 1P63A switch box

              Cables and Accessory

Packing

Before each loading and shipment, our factory has special personnel to check QC inspection of qualified products.

They distinguish and mark the area to place, ensure the shipment quantity, model, customer name is accurate, only after the standard is allowed to load containers.

Ensure that you receive complete and correct goods at the end.

Carton and Wooden box packing optional-Solar panel

Solar panel packing
Wind turbine packing

Easy drawing of 3kW hybrid solar wind system

48vdc gel battery 3kw hybrid solar and wind energy storage system drawing↓

VFD with hybrid solar and wind energy system connection

More installation manual and video, please click here contact us

We have oversea installation service. The engineer will arrive at the installation site within 10 days after the goods arrived at port.

Installation manual
3kW hybrid solar wind power system installation manual

Wind Products FAQ

Q: Do wind turbines make noise? How to solve the noise problem?

A: The wind turbine noise is less than 40 decibels for indoor impact. It’s like the noise our pets (cats or dogs) make when they sleep outside our bedroom.

The impact on our daily life is almost zero.

Click the below picture to check the test video and learn how to solve the noise problem.

Wind turbine noise level



Q: Can I customize one?

A: Of course, you can customize the most efficient hybrid solar wind power system. Your exclusive expert is waiting. To provide you with any energy solution, customized according to different power consumption, actual use of equipment, scenarios etc. Solar wind systems come in different configurations.

Q: Where do I better install the wind turbine?

A: Wind turbines below 1kW can be installed on the roof. But those above 1kW are recommended to be installed at least 100m from the home. This is to ensure that there are no buildings or other obstructions higher than the windmill height near the wind turbine.

Distance of installed windmill

For installing the guy cable pole, please check below details of the tower picture. PVMARS wind turbine tower includes all installation parts, ensure you received goods completely.

details of the tower picture

Q: What is the estimated power production?

A: 1kw or 2kw wind turbine system will produce an estimated 6-12 kilowatt hours (kWh) per day, And if your wind speed is good, it will give you more power every day (click here about Kenya’s farm case to learn how to check local wind speed) , And here is the 2kw and 1kw wind turbine power curve. The power is relative to the wind speed.

1kW wind turbine working curve

2kW wind turbine working curve

Q: What can you expect from PVMARS Solar?

A: In addition to providing products, PVMARS solar also provides free on-site survey, customized design solutions, production, installation and maintenance one-stop services.
